65+35 cable extrusion production line


65+35 cable extrusion production line

A.Equipment Application

The unit is used for the production of medium and small section copper core insulation coating, mainly for thermoplastics such as polypropylene, soft polyvinyl chloride and polyethylene.

B.Main technical parameters
The screw diameter φ65(mm)
The screw length to diameter ratio 25:01:00
The output SPVC:120kg/h
Before the sheath of cable diameter φ3~φ20mm
After the sheath of cable diameter φ5~φ25mm
Maximum traction 500kg
The length of the sink 12m
Equipment center high 1000mm
The power supply Three-phase 380±10%,50Hz with neutral wire
C.Equipment Composition
φ1600 end of shaft motorized 1 set
φ630 double wheel tensioning device 1 set
SJ-65×25 units came out 1 sets of
Sj35x article 25 bedroom injection machine 1 sets of
φ25 co-extrusion head 1 only
Drying and feeding device 1 sets of
cooling water tank(12 m in cold water tank) Article 1.
Blow dry device 1 sets of
TQD-500 tractors 1 set
Spark machine 1 set
Caliper gauge 1 set
φ1600 end line frame 1 set
